High Temperature Pressure Transmitter Manifold Designed With Temperature Range Negative 40 To 150 Degrees Celsius And OEM Customized Support

Product Description:

The Pressure Transmitter Manifold is an essential accessory designed to enhance the performance and reliability of pressure measurement systems. Engineered with precision and compatibility in mind, this manifold is compatible with most pressure transmitters, making it a versatile choice for various industrial applications. Whether you are upgrading an existing setup or installing a new system, this manifold ensures seamless integration with popular models such as the Emerson 3051CD3A22A1AM5B4L1Q4 and the 3051CD1A02A1JM6K5S5Q4, providing reliable and accurate pressure readings.

Constructed from premium materials, the Pressure Transmitter Manifold offers exceptional durability and resistance to corrosion and wear. Available in multiple material options including 316L stainless steel (SST), Alloy C-276, Alloy 400, tantalum, gold-plated 316L SST, and gold-plated Alloy 400, this manifold can withstand harsh operating environments and aggressive process media. The choice of materials allows users to select the optimal configuration for their specific application needs, ensuring longevity and consistent performance even under demanding conditions.

One of the standout features of this manifold is its advanced output capabilities. It supports the 4-20 mA HART communication protocol, a widely used standard in the process industry that enables digital communication over conventional analog signals. This means that in addition to transmitting standard analog signals, the manifold can provide enhanced data and diagnostics, facilitating improved process control and monitoring. The 4-20 mA HART output ensures compatibility with a broad range of control systems and enables easy integration into modern industrial networks.

In terms of diagnostics, the Pressure Transmitter Manifold is equipped with comprehensive diagnostic functions that help maintain system integrity and reduce downtime. It offers basic diagnostics to monitor the general health of the transmitter and manifold assembly. Process alerts provide real-time notifications about deviations or issues within the process, allowing for prompt corrective actions. Loop integrity diagnostics ensure that the signal loop remains reliable and free from faults, which is critical for maintaining accurate measurements. Additionally, plugged impulse line diagnostics detect blockages in the impulse lines, a common cause of measurement errors, thereby enhancing the overall reliability of the pressure measurement system.

The manifold’s design is not only functional but also visually distinctive, featuring a striking blue color that makes it easily identifiable among other instrumentation components. This color coding aids in quick maintenance and troubleshooting, especially in complex setups where multiple devices are installed. The ergonomic design ensures ease of installation and maintenance, minimizing downtime and operational disruptions.

Overall, the Pressure Transmitter Manifold is a high-quality, reliable, and versatile solution for pressure measurement applications. Its compatibility with major pressure transmitters such as the Emerson 3051CD3A22A1AM5B4L1Q4 and 3051CD1A02A1JM6K5S5Q4, coupled with its robust construction from premium materials and advanced diagnostic features, makes it an ideal choice for industries ranging from oil and gas to chemical processing and beyond. By integrating this manifold into your pressure measurement system, you can achieve enhanced accuracy, improved system diagnostics, and greater operational efficiency.

Features:

• Product Name: Pressure Transmitter Manifold
• Material Options: 316L SST, Alloy C-276, Alloy 400, Tantalum, Gold-plated 316L SST, Gold-plated Alloy 400
• Diagnostics Features:
  • Basic Diagnostics
  • Process Alerts
  • Loop Integrity Diagnostics
  • Plugged Impulse Line Diagnostics
• Range Down Up To: 150:1
• Compatibility: Compatible With Most Pressure Transmitters
• Temperature Range: -40 to 150 °C
• Model Reference: 3051CD1A02A1JM6K5S5Q4
• Designed for use with Differential pressure transmitter applications
• Ensures accurate measurements in Differential pressure transmitter systems

Technical Parameters:

Applications:

The Rosemount Pressure Transmitter Manifold, model number 3051CD0A22A1AM5B4DFE5, is a highly versatile and reliable instrument designed for a wide range of industrial applications. Originating from China and built with premium materials such as 316L stainless steel, Alloy C-276, Alloy 400, Tantalum, and gold-plated variants, this manifold ensures exceptional durability and corrosion resistance in demanding environments. It is engineered to handle maximum pressures up to 2000 Psi (137.89 Bar) differential, 2000 Psig (137.89 Bar) gage, and 4000 Psia (275.79 Bar) absolute, making it suitable for high-pressure process control systems.

This manifold is especially useful when paired with differential pressure transmitters like the Rosemount 3051CD1A02A1JM6K5S5Q4 model, providing seamless integration and enhanced measurement accuracy. Its advanced communication capabilities support multiple protocols including 4-20 mA HART®, WirelessHART®, FOUNDATION™ Fieldbus, PROFIBUS® PA, and 1-5 V low power HART®, enabling flexible connectivity in various automated control systems. This makes it an ideal choice for industries that demand precise data transmission and real-time diagnostics.

The manifold’s comprehensive diagnostic features, such as basic diagnostics, process alerts, loop integrity diagnostics, and plugged impulse line diagnostics, contribute to improved system reliability and minimized downtime. These diagnostics are critical in environments where continuous monitoring is essential, such as oil and gas, chemical processing, power generation, and water treatment plants. Additionally, the device is designed to operate effectively in environmental humidity levels ranging from 0 to 100%, further broadening its application scope.

In practical terms, the Rosemount Pressure Transmitter Manifold is used in scenarios requiring accurate pressure measurement and control, such as differential pressure flow measurement, level measurement in pressurized tanks, filter monitoring, and pump control systems. It facilitates easy isolation, calibration, and maintenance of the connected pressure transmitters like the 3051CD1A02A1JM6K5S5Q4, ensuring operational efficiency and safety. Overall, this manifold is an essential component in modern industrial instrumentation, delivering precise pressure management in challenging process conditions.
